The SunGoldPower LFP 6000 Watt DC 24V AC 120/240 Split Phase Inverter Charger is a top high quality low frequency power inverter, built for running your whole house (small home), Business, RV System, Trailer or Boat Application, this inverter charger is perfect for your off grid system or an emergency backup supply. The split-phase inverter requires 240VAC input and will output 110/120 or 220/230/240VAC, and it can output 50 or 60Hz via the SW4. It is capable of producing 2 legs of 110V, making this inverter perfect for home and business applications with a 220 panel in place.
Three in one product:
★ The 6000 watt power inverter transforms 24V DC power stored by batteries to AC electricity that can power the tools and appliances.
★ It has a built-in 90 amp battery charger which help the grid or generator to recharge the battery.
★ The transfer switch allows the product to automatically switch between shore power and battery power within 10 mili seconds.
Main Features:
*6000W Low Frequency Pure Sine Inverter With Charger.
*AC/Battery Priority Selector.
*Automatic Generator Start.
*Safety and Convenient.
*The low frequency inverter can power all kinds of appliances.
*LCD Display, Remote Control.
*Low Idle Consumption.
*9 battery type settings for charger.
*Multi Stage Smart charger 90+/-5A, charger can be disable.
*10msec typical transfer time.
Inverter Output:
*Continuous Output Power: 6000W
*Surge Rating: 18000W (20 Seconds)
*AC Output: AC 120V and AC 240V
*AC Input: 240V
*Output Wave: Pure Sine Wave (bypass mode)
*Typical Transfer Time: 10ms (MAX)
*Nominal Efficiency: >88%
DC Input:
*Nominal Input Voltage: 24.0Vdc
*Minimum Start Voltage: 20.0Vdc
*Low Battery Alarm: 21.0Vdc-22.0Vdc
*Low battery Trip: 20.0Vdc-21.0Vdc (select by SW1)
*High Voltage Alarm: 32.0Vdc
*Low battery Voltage Restart: 26Vdc
*Idle Consumption: 77W
*Power Saver Mode Idle Consumption: 29W
AC Charger :
*Charger Rate: 90+/-5A
*AC input Range (Grid or Generator): 140V-270VAC/184V-253VAC (select by SW2)
*Over Charge Protection Shutdown: 31.4V
*Selectable Charge Setting based on battery type
*Adjustable charge current: off 0%-100%
*3-step intelligent battery charger
Packaging:
*6000W 24V Low Frequency Pure Sine Inverter
*English Manual
*Remote Control
*BTS Cable
*Unit Weight: 76.7LB
*Unit Size: 25.6 x 9.1 x 7.5 inch
*Shipping Weight: 85.5LB
*Shipping Size: 30.3 x 13.4 x 12.8 inch
Frequently Questions Answer
1. What does it mean 240vac split phase?Would it imply I can use it as 120v or 240v?
Dear Customer, 240V split phase means: it has two different outputs, one is 120V output, another one is 240V output. one leg is 3000w. if you connect with 240v load, there will be 6000w output, if you connect with 120v load, there will be 3000w output, thanks.
2. Can this product charge lithium batteries such as life po4 from battle born brand?
Dear Customer, yes, it can charge lithium battery, pls check the manual, thank you
3.How much power can a 6000-watt inverter continuously provide?
A 6000-watt inverter can technically provide up to 6000 watts, it is advisable to keep continuous loads around 4800 watts or less to maintain efficiency and avoid overheating or damaging the inverter. Always consider the total wattage of the devices you plan to connect, including any surge or starting wattage for appliances with motors.
4. What does the" AC abnormal" on the screen mean for this inverter?
If 6000 watt power inverter screen displays "AC abnormal", it may be caused by three reasons:
1. Do you connect to the AC mains supply? If not, it will display "AC abnormal" when the inverter operates under the inverter mode.
2. If yes, what is your voltage of AC mains? If the AC mains aren't in the range in which the inverter can be accepted, it will also show that.
3. In battery priority mode(sw5 is at position #1), if there is an AC mains input when the battery power is sufficient, the AC mains voltage can also be detected, but the display will still show "AC abnormal".
If it belongs to these three situations, it is normal, because this is how our software is set up.
5. Is a 6000-watt power inverter suitable for off-grid systems?
Yes, a 6000-watt power inverter is a solid choice for off-grid systems, capable of supporting a variety of loads and providing flexibility for energy needs. Just ensure proper sizing of your battery bank and careful planning of your power usage to maximize efficiency and reliability.
