Pure Sine Inverter With Charger

6000W DC 48V Split Phase Pure Sine Wave Inverter With Charger

Hightlight:

  • ★ This LFP Series Pure Sine Wave Inverter is a combination of an inverter, battery charger and AC auto-transfer switch. low frequency, low Idle Current, BTS cable, remote control.

  • ★ AC/Battery Priority: Our inverter is designed with AC priority by default, you can choose the battery priority by SW5 switch.

  • ★ Adjustable Charging Current: The max charge current can be adjusted from 0%-100% via a liner switch.

  • ★ Auto Gen Start: The inverter can start up a generator when battery voltage goes low. and turn the generator off after battery charging is finished.


QUESTIONS & ANSWERS

Have a Question?

Be the first to ask a question about this.

Ask a Question

Features

Main Features:

  • 6000W Low Frequency Pure Sine Inverter With Charger.
  • AC/Battery Priority Selector.
  • Automatic Generator Start.
  • Safety and Convenient.
  • The low frequency inverter can power all kinds of appliances.
  • LCD Display, Remote Control.
  • Low Idle Consumption.
  • 7 battery type settings for charger.
  • Multi Stage Smart charger 60+/-5A, charger can be disable.
  • 10msec typical transfer time.

    Packaging:

    • 6000W 48V Low Frequency Pure Sine Inverter
    • English Manual
    • Remote Control
    • BTS Cable
    • Unit Weight: 72LB
    • Unit Size: 27.5 x 12.2 x 11.8 inch
    • Shipping Weight: 79LB
    • Shipping Size: 30 x 13.3 x 12.9 inch

    6000W 48V Split Pure Sine Wave Inverter

    Specification

    Main Specification:

    Inverter Output:

    • Continuous Output Power: 6000W
    • Surge Rating: 18000W (20 Seconds)
    • Output: AC 120V and AC 240V ,60HZ
    • AC Input:240V
    • Output Wave: Pure Sine Wave (bypass mode)
    • Typical Transfer Time: 10ms (MAX)
    • Nominal Efficiency: >88%

      DC Input:

      • Nominal Input Voltage: 48.0Vdc
      • Minimum Start Voltage: 40.0Vdc
      • Low Battery Alarm: 42.0Vdc-44.0Vdc
      • Low battery Trip: 40.0Vdc-42.0Vdc (select by SW1)
      • High Voltage Alarm: 64.0Vdc
      • Low battery Voltage Restart: 52Vdc
      • Idle Consumption: 81W
      • Power Saver Mode Idle Consumption: 30W

        AC Charger :

        • Charger Rate: 60+/-5A
        • AC input Range (Grid or Generator): 90V-135VAC/100V-135VAC (select by SW2), 140V-270VAC/184V-253VAC (select by SW2)
        • Over Charge Protection Shutdown:62.8V
        • Selectable Charge Setting based on battery type
        • Adjustable charge current: off 0%-100%
        • 3-step intelligent battery charger
            User Manual


            Download LFP Series Pure Sine Wave Inverter/Charger User's Manual

            FAQ

            Frequently Questions Answer

            1. Is this unit a grid-tie inverter?

                Dear Customer, this is a pure sine wave inverter, it's off the grid one, thanks.

            2. How many can I put it parallel?

                Dear Customer, several inverters can not be  connected in parallel, thanks.

            3. Can I hook my solar panels directly to the controller or do I still need a solar battery controller?

                Dear Customer, you need have an external solar controller if you want it work with solar panels, thanks.
